FLAMESAVE: Intumescent Paint for Metal & Structural Steel
Field : Intumescent Paint for Metal & Steel
Brand : MIVIKO
INTUMESCENT FIRE-RETARDANT PAINT FOR STRUCTURAL STEEL
FLAMESAVE - Nanocomposite intumescent paint, water-based, 1 component used for fireproofing of iron and steel structures with a fireproof time of R90–R180.
ADVANTAGES
Water-based: Clean, safe & environmentally friendly
FREE VOC
FREE Halogen, APEO , Borates or toxic heavy metals
Intumescent layer : Low (≤ 2cm)
Good adhesion even on alkyd or epoxy painted steel surfaces
Odorless, fast drying
Compliant with DIN EN 13501-2 fireproof standard
APPLICATION
Fire - retardant time required | Standard thickness of one dried layer | Number of Layers | Time to paint the next layer | Thickness of finishing layers after drying | Consumption (kg/m2) |
90 minutes | 250 - 350 µm/layer | 2 | 3 - 6 hours | 550 – 700 µm | 0,9 – 1,1 |
120 minutes | 250 - 350 µm/layer | 3 | 3 - 6 hours | 800 – 950 µm | 1,2 - 1,4 |
150 minutes | 330 - 400 µm/layer | 3 | 4 - 7 hours | 1000 – 1200 µm | 1,45 – 1,7 |
180 minutes | 330 - 400 µm/layer | 4 | 4 - 7 hours | 1200 – 1500 µm | 1,55 – 1,8 |
PACKAGING: 20 kg
